TIG / GTAW Yellow Steel Pipe Welding Machine With Automatic Wire Feeding

TIG / GTAW Yellow Steel Pipe Welding Machine With Automatic Wire Feeding
TIG / GTAW Yellow Steel Pipe Welding Machine With Automatic Wire Feeding

Large Image :  TIG / GTAW Yellow Steel Pipe Welding Machine With Automatic Wire Feeding

Product Details:
Place of Origin: China
Brand Name: Hyzont
Certification: CCC
Model Number: OTH-50
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Wood Case
Delivery Time: 7 days
Payment Terms: L/C, T/T
Supply Ability: 100Set a Month
Contact Now

TIG / GTAW Yellow Steel Pipe Welding Machine With Automatic Wire Feeding

Description
Name: Orbital Welding Machine Model: OTH-50
Application: Pipe TIG/GTAW Automatic Welding Input Power: 380V-440V
Out Put: MAX315 A Type Of Weld: TIG With Wire Feeding
Pipe OD: Φ50-168mm Welding Head Weight: 8Kg
Highlight:

TIG GTAW Automatic Wire Feeding

,

Yellow Steel Pipe Welding Machine

,

Consistent Orbital Pipe Welds

TIG/ GTAW Pipe Welder with automatic wire feeding Steel Pipe Welding Machine ​

Weld Head Model: OTH-50

Welding Power Source Model: OBT-315

Application:

    Tube dia Range:Φ50-168mm

This automatic tube welding machine comprises an OBT-315 TIG welding power source and an OTH-130 open welding head, suitable for medium-wall carbon steel and stainless steel pipe welding. Its compact structure is easy to use on site, delivering good weld surface quality and fast welding speed.

Features :

  • Automatic all position TIG pipe to pipe welding with/without wire feeding
  • Compact structure design, stable rotation with small rotating inertia
  • Oscillation, multi-passes welding process
  • Suitable for connection of tube to tube, tube to flange, tube to elbow, tube to valve
  • Water circuit cooling, achieving long time working
  • This machine  is modular in design, compact in design and compact in structure.
  • The main components are aluminum structure and stepless adjustable clamp to fix the pipe diameter.
  • Gapless gear transmission structure design with automatic AVC

Specification

Model MWA-315A
Welding source Panasonic YC-315TX
Power source type Inverter
Welding Current 5-315A
Duty Cycle 315A/60%；250A/95% ；244A 100 %
Input Voltage AC380V ± 10 % 50/ 60 Hz
Total Power 8.3KVA
Cooling Build-in Water Cooling System
Display 7" touch screen
Programs Storage 80
Insulation Grade F
Protection Class IP21
Weight 120KG
Dimension 740*520*910
Control Function

Argon gas control

Continuous welding current and pulse current control

Welding head rotation control

Wire feeding control

AVC control with on/off function for manual adjustments

Detailed Pictures

TIG / GTAW Yellow Steel Pipe Welding Machine With Automatic Wire Feeding

                              Size of  OTH-130 Welding Head

TIG / GTAW Yellow Steel Pipe Welding Machine With Automatic Wire Feeding

                      TIG   Tube Welding  by OBT315

TIG / GTAW Yellow Steel Pipe Welding Machine With Automatic Wire Feeding

                                OBT-315 Steel Tube Welding Power Source
