stainless steel return bend automatic orbital welding machine order to build machine as customer requirements

Place of Origin China
Brand Name HYZONT
Certification CE
Model Number MWH-16A
Product Details
Name:
Return Bend Automatic Orbital Welding Machine
Model:
MWH-16A
Application:
Stainless Steel Condenser U Bend Tube Auto Weld Fabricating
Weld Current:
Max. 200Amp
U Tube Material:
Stainless Steel And Carbon Steel
U Tube Thickness:
1-3mm
Type Of Welding:
TIG/GWAT (No Wire Feeding)
Place Origin:
China
Voltage:
220V/50-60Hz
Condition:
Brand New
Weight:
13Kg + 23Kg
Color:
Yellow And Gray
High Light:

automatic tube welder

,

automatic orbital welding machine

Payment & Shipping Terms
Minimum Order Quantity
1Set
Price
negotiable
Packaging Details
Flight Case
Delivery Time
15 Days after Payment
Supply Ability
100 Sets a month
Product Description

stainless steel return bend automatic orbital welding machine order to build machine as customer requirements

stainless steel return bend automatic orbital welding machine order to build machine as customer requirements 0

Application:

This is a special designed TIG welding head for stainless steel condenser U tube automatic welding, which is almost same with orbital welding process

  • Condenser U tube welding
  • Evaporator U tube welding
  • Heat exchanger fabricating

Features:

Customized design, suitable for all type U tube

Quick-install Clamps, easy to use

Low labor cost and high efficiency welding

Collision-free and good contact narrow space U tube welding

Heat- resisting components with compact design, light and durable

Water circuit cooling design for long time working



Specification:

Model MWH-16A
Material Carbon steel, Stainless Steel, Titanium Alloy
Tube Fitting Plugged type return bend Pipe
Welding Process TIG/GTAW (no wire feeding)
Tube OD(mm/inch) 12.7-15.88
Tube Wall Thickness(mm) ≤3mm
Tungsten OD(mm) 1.6
Rotating 360 degree free rotated and Auto reset ;all position welding;
Rotation speed(rpm) 0.3~6
Protective Gas Argon
Cooling Water
Cooling Flow(ml/min) 1000ml/min
Cable Length 6m
Main Dimension(mm)
Weight(kg) 6kg
Dimension(mm) 377*38*100
