Single Table Laser Cutting Equipment / 2Kw CNC Laser Cutting Machine Sheet Metal
Product Details
| Name: | CNC Fiber Laser Cutting Machine | Model: | TF EDGE 3015-E |
|---|---|---|---|
| Brand: | TAYOR | Cutting Area: | 1500X3000mm |
| Power Source: | 2Kw | Controller: | CyperCut |
| Cutting Thickness: | 0.5-12mm | Moving Speed: | Max 60m/min |
| Highlight |
2kW Single Table Laser,TF EDGE Sheet Metal Cutting,CNC Laser Cutting Equipment |
||
Product Description
1500 x 3000 Single Table CNC Fiber Laser Cutting Machine 1 kW Laser Cutting Machine
Model: TF3015 EDGE-E
Applications:
Fiber lasers are the newest development in laser cutting. The laser beam is created by an active fiber and transmitted over a transport fiber to the machine cutting head. Fiber lasers are significantly smaller than CO2 lasers and generate twice as much power from the same amount of current. A fiber cutting system is primarily suited for processing thin to medium-thick sheet metal. It also cuts non-ferrous metals (copper and brass).
CNC fiber laser cutting is capable of processing various metal types and play an essential part in industrial and commercial activities.
This machine widely applied in
Features
Specification
| Cutting Area(mm) | 1500 x 3000/2000 x 4000 |
| X-axis (mm) | 3000/4000 |
| Y-axis(mm) | 1500/2000 |
| Z-axis(mm) | 120 |
| Cutting Thickness(mm) |
Mild Steel: 0.5-12 Stainless Steel: 0.5-5 Aluminum: 0.5-4 |
| Laser cutting accuracy(mm) | 0.1-0.2 |
| Machine Tool repositioning accuracy(mm) | 0.025 |
| Machine Tool moving accuracy(mm) | 0.05 |
| Max Moving Speed(m/min) | 50 |
| Accelerated speed (G) | 1 |
| Laser Power (w) | 1 kW |
| Total Power (Kw) | 30 kW |
| Machine Dimension (LxWxH) | 5150 x 2282 x 1290 |
| Weight (Ton) | 3500Kg/4800Kg |
| Cutting Table | Single Cutting Table with dust exhausting fan |
Detailed Pictures
CNC fiber laser cutting machine Operation interface
1 kW Fiber Laser Cutting Machine Package and Delivery
Order information
| Order Code | TF3015 EDGE-E |
| Packing | Wooden Case |
| Packing Size | 5800 x 2200 x 1800 mm |
| Packing Weight | 4000-5000Kg |
| Delivery Time | 25 Days after payment |
TF3015 EDGE-E CNC Fiber Laser Cutting Machine Youtube Video Link:
https://www.youtube.com/watch?v=xgHAmL8MZ-E
