Features
1. Steel hollow beam design ensures good heat dissipation without deformation.
2. The gear-rack driving motions without engagement gap ensure the machine running smooth at high speed.
3. Fully functionalized CNC system and optocoupler device enhance the super anti-jamming capability of the plasma system.
4. World’s top branded components and circuits ensure long service life.
5. Multiple cutting torches can be configured. Both flame and plasma torches are optional to meet the needs of cutting different materials in a range of thickness.
Table type CNC plasma cutting machine | ||||
Model | TNC-1325 | TNC-1530 | TNC-1560 | |
Effective Cutting area WIDTH*LENGTH(m) |
1.5*3.0 | 1.5*3.0 | 1.5*6.0 | |
Approximate Machine table board WIDTH*LENGTH(m) |
2.0*4.0 | 2.0*5.0 | 2.0*7.0 | |
Width: 1.3m,1.5m, 1.8m Length:2.5~5m | ||||
Configuration | ||||
Cutting model | Give priority to with plasma/ The flame can be selected | |||
Cutting speed | No-load speed: 20m/min without shake | |||
Loading speed: 0~15m/min with high stability | ||||
Cutting thickness |
0~30mm with plasma / Specific cutting thickness depends on the plasma power Advice cutting <14mm metal; not advice support frame to bear too much weight |
|||
Drive mode | Double-sides Driving | |||
Drive motor | Servo motors for driving | |||
Torch Height Control | ||||
Arc THC | HYD brand | |||
Rail | ||||
Precision | PRECISION HIWIN brand LINEAR RAIL, | |||
Precious linear Square guide rail and linear guide rail; better than round guide | ||||
The linear tolerance of two guides on X axis is less than 0.05mm;X and Y axis vertical tolerance is less than 0.05mm; | ||||
Cutting Torch | ||||
Model | plasma cutting (Main cutting model) | |||
Torch No. | 1 plasma torch; | |||
Power&Software&System | ||||
Usable Plasma power | 120A | |||
Nesting software | Fastcam software from Australia | |||
Cutting platform | INCLUDE | |||
Gas-guide tube | KOREA SAMSAN | |||
Auto-system | BEIJING SATRFIRE |
