Steel Frame 1000W Integrated CNC Plasma Cutting Table

Steel Frame 1000W Integrated CNC Plasma Cutting Table
Steel Frame 1000W Integrated CNC Plasma Cutting Table

Large Image :  Steel Frame 1000W Integrated CNC Plasma Cutting Table Get Best Price

Product Details:

Place of Origin: China
Brand Name: Hyzont
Certification: CE
Model Number: CNCTG-1530

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: wooden case
Delivery Time: 3 weeks
Payment Terms: T/T, Western Union, MoneyGram, L/C
Supply Ability: 10000 set year
Detailed Product Description
Name: CNC Plasma Cutting Table Model: LASER-3015A
Certification: CE
High Light:

Integrated CNC Plasma Cutting Table

,

1000W CNC Plasma Cutting Table

Integrated Steel Frame Fiber laser Cutting Table for high quality high accuracy 500W, 1000W, 1500W, 2000W, 3000W, 4000W





Main application
Suitable for stainless steel, carbon steel and some other metal materials precise cutting, applicable for aerospace technology, rocket, plane, robot, elevator, steamship and automobile manufacturing and metal parts processing industry for metal plate, advertisement, kitchenware, bit tool, hardware etc.



Unique Advantages of Fiber lasers:
1. The electrical efficiency of greater than 30% wall-plug efficiency.Air-cooled or minimal cooling requirements
2. Easy operation and maintenance
3. Low operation cost, quality cutting, high efficiency.
4. Minimal spare parts
5.  Fiber laser has a wide choice of industrial interfaces and can be easily interfaced to standard industrial controls.
6. The same fiber laser can do cutting, welding, drilling, and cladding, Delivery fiber can support multiple workstations with long distance.
7.  All parts (machine frame, laser generator, beam delivery system, axes of movements, CNC, electromechanics) are integrated with a single, easily transportable element. The floor space requirement is the lowest possible compared to the machine axes strokes.
8. It does not require foundations.

Technical Parameter

Item Parameter
Model series LASER-3015A
Working area(mm) 3000×1500;4000×2000;6000×2000;Customized
X.Y driver model Rack and pinion
Z-axis stroke 120mm
Power 3 phase 380V 50HZ;Or customized
Laser brand IPG/Nlight/raycus
CNC control system Fagor/Germany PA8000/Cypcut
Servo drive system Yaskawa/Fagor
Max acceleration speed 0.5~1.5G
Cutting kerf width 0.15-0.3mm
Cutting head Germany Precitec
Machine body Hyzont
Cross Beam Hyzont
Exchange working table Hyzont
Gearbox Germany STOBE
X,Y Rack and pinion Germany Atlanta
Ball screw Rail Taiwan Hiwin
Bearing NSK
Drag Igus
Pneumatic system Japan SMC,
Height sensor Germany precitec
Electrical components Schneider
CAD/CAM software Israel CNCKAD/ Fastcam professional
Functions Description
Follow-up function Metal surface height auto-tracking control
Power supply control Laser power slope control
Rollback function Reverses NC program
Breakpoint return function Re-production after malfunction
Angle turning function Angle cutting parameter setting
Multi piercing function Pulse, blast, progressive, fast
Lead function Lead function setting
Auto edge-finding Auto finding a workpeice coordinate system
Ping-pong function Increase cutting efficiency
Common line cutting Increase cutting efficiency
Marking function Specialized making device


Laser cutting machine cutting samples

Steel Frame 1000W Integrated CNC Plasma Cutting Table 0
